Is a 700r4 the same as a 4l60

In 1990, GM decided to code and renamed their transmissions, the 700R4 is best described as a 4 speed, longitude transmission rated for vehicles around 6000 lbs. It was this information that was used to change its name to 4L60; therefore, a 700R4 and 4L60 are the same transmission.

What is the difference between a 700R4 and 4L60?

You can’t tell the difference between a 700R4 and a 4L60E by the oil pan as they are nearly the same. If the transmission has a large 18-pin electronic connector above the passenger side pan rail, it’s a 4L60E, as seen here. If it has a cable connection near the cooler lines on the passenger’s side, that’s a 700R4.

When did GM switch from 700R4 to 4L60E?

In 1990, the 700R4 was redesignated as the 4L60 (4-speeds, Longitudinally positioned, 6000 lbs. GVW). This was a change in name only with no significant mechanical changes associated.

Will a 4L60 converter work in 700R4?

All 4L60E transmissions through 1997 have the same 30 spline input shaft as 1984-1993 700R4 transmissions. 1998-2000 4L60E transmissions may or may not have the same input shaft as a 1984-1993 700R4 transmission. This torque converter will not work with a LS type motor, except a C5 Corvette will work.

Can you use a 700R4 with a LS motor?

You could use the 700r4 behind a LS motor, but I dont recommend it. I’d sell it and then but a 60e or 80e. Even it if was just rebuilt. The only time that i’d consider running the 700r4 would be if it was a built racing trans which usually runs about $1200.

Is a 4L60 the same as a 4L60E?

The 4L60 designation, while the same for the 4L60 and 4L60E represents the fact the transmissions are four gears, Longitudinally positioned, The engine is capable of supporting a 6,000-lb Gross Vehicle Weight Rating (GVWR).

Does a 4L60 have overdrive?

The 4L60-E is an automatic shift, four-speed overdrive, longitudinally positioned transmission. It is now widely considered to be the best rendition of the finest overdrive automatic transmission ever produced.

When did GM stop using 4L60?

The TH700R4 was renamed “4L60” (RPO MD8) following the new General Motors naming convention when the electronic version, 4L60E (RPO M30), was phased in as the 4L60 was being phased out. This happened in 1993 for trucks, vans, and SUVs, and 1994 for rear wheel drive passenger cars.

What size torque converter is in a 700R4 transmission?

700R4-1650Model:700-R4 30 SPLINEStall:1650 Low StallSize:12″Turbine:30 Spline

What year did GM stop using the 700R4?

1992 was the last year of widespread usage of the 700R4 (4L60). The 1993 Camaro, Corvette and Typhoon were equipped with the last production 700R4. The last design change of the 700R4 was an added checkball to the valve body.

Article first time published on

What engines are compatible with a 700r4 transmission?

MODELENGINECAPRICE3.8L / 5.0LCAMARO2.8L / 5.0LSUBURBAN6.2LS10 PICKUP2.5L / 2.8L

What transmission bolts up to a 5.3 Vortec?

Registered. NV3500 will bolt up, that’s the transmission that came behind some factory 4.8s and 5.3s.

What does 4L60 stand for?

In 1990, the 700-R4 was redesignated the 4L60, with “4″ meaning four-speed, “L” for longitudinal installation (north/south), and “60” meaning light-to-medium-duty use and 6,000-pounds gross vehicle weight. Although the 700-R4 had a new designation, the same old driveability and shift programing issues persisted.

Does a 4L60 need a computer?

Externally, all it needs is a 12-volt source and an engine-vacuum reference. However, if your trans is, in fact, a 4L60E, running it off a computer is mandatory. On “E” transmissions, the computer controls everything: TCC lockup, gear changes, shift quality and firmness, and line pressure.

What year 700R4 is best?

Generally, 1987 and up TH700R4s or 1990-’93 4L60 units are the most desirable. Before trying to install this transmission in your vehicle, you should thoroughly check the unit and refurbish it, if necessary.

Will a 4L60 bolt up to a 350?

The 4L60E will bolt straight up to your 350. :yes: You will need some way to control the tranny though. The OD is electronically controlled, hence the “E” at the end of the 4L60.

What year 4L60E are compatible?

Year RangesTransmissionPan/Filter19934L60-4L60EShallow1994-19964L60EShallow19974L60EShallow – Early Deep – Late1998-20004L60EDeep

How do I know if I have 4L60 or 4l80?

Appearance. The 4L80E can be told apart from the 4L60E by looking at their transmission fluid pan. This is because the 4L80E has a pan that is oval in shape whereas a rectangular pan is featured by the 4L60E. Another disparity between both devices is the number of bolts used to secure the transmission to the engine.

How do I identify a 700r4 transmission?

The 1st number is the year model of the transmission. …
The next 2 or 3 letters identify the model of the transmission. …
If you find 2 letters, the transmission is made between 1982-1985.
Wirings = 4L60.
Aux TV Cable = 700r4.
Red = Okay.

How do I identify a torque converter?

Identify Converter Markings If your torque converter is a welded unit, you need to search the exterior of the unit for any identifying marks, most notably on the engine side or “bottom” of the converter. Note any identifying marks you find.

What is the 4L60E in?

The 4l60e transmission can be found in many mid 90’s to mid 2000’s GM cars, truck, vans, and SUV’s. The 4l60e comes in either a 4 wheel drive (4×4) or 2 wheel drive (2wd).

What did 4L60E come in?

Introduced in 1993 for trucks, vans, and SUVs, then in 1994 for rear-wheel-drive passenger cars, the 4L60E from General Motors is an evolution of the Turbo-Hydramatic 700R4 and replaced the tried and true TH350.

How do I identify a Chevy truck transmission?

Chevrolet transmissions can be manual or automatic. Automatic transmission on a Chevy can be identified in one of two ways: You can look at the size of the pan on the transmission or you can search for the identification number that has been stamped somewhere on the casing.

How do I find out what transmission I have?

Open the driver’s side door and find the white card on the side of the door that is filled with small black lettering. This card contains specific details about the year the car was made, its transmission, engine specifications and other details. Underneath or beside the “TR” symbol will be a number code.

What transmissions bolt up to a Chevy 350?

The 350 has had TH200 , TH350, TH400 , 4L60 and more than likely the 4L80 automatics behind it. My truck with the Chevrolet 350 engine utlizes the TH400 . There would have been a variety of manual gear boxes behind the 350 as well.

What transmission do I have by VIN number?

Another way is to crawl under the vehicle and look for part numbers. Using a good flashlight, look for part numbers stamped into the transmission pan or the transmission itself. Your local auto part store or dealer will be able to cross-reference the numbers to determine the kind of transmission the part belongs to.

Are there different types of 700R4 transmissions?

The 700R4 transmission first gear, second gear, third gear, fourth gear, and reverse gear are 3.06, 1.63, 1, 0.7, and 2.9 respectively. Its lower first gear ratio provides excellent performance for low vehicle speeds. … The torque that can be handled by a 700R4 transmission varies depending on its production year.

Will a 700R4 bolt up to a 4.3 Vortec?

The 700R4 will bolt up to the engine. No problem.

What years did Chevy make the 700R4 transmission?

The General Motors 700R4 transmission was manufactured by Chevrolet in 1981 to run with 1982 model year vehicles. It is a four-speed automatic transmission with overdrive and was introduced as a way to make V8-powered cars and trucks more efficient.

Will a 6.2 bolt up to a 4L60E?

Yeah, it will bolt up fine, but you won’t be able to make it shift. The 4L60E was electronically controlled and if you don’t have the controller it won’t work.

How much HP can a 4L60E handle?

Their Stage 2 Pro Race transmission can handle gobs of power while their Invincible Black Edition 4L60E trans can support over 1,000 ponies.
